Flow Control, Subplate Mounted Valve – FS Series
*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.
Parker’s FS series flow control valve offers superior construction and high versatility due to its variety of materials, sizes and port styles. It can be used in both the mobile and industrial markets.
The FS series flow control valve comes in 5 sizes ranging from 5 to 40 GPM.
Markets:
• Factory Automation
• Machine Tools
• Marine
• Material Handling
• Mining
• Miscellaneous Industrial
• Miscellaneous Manufacturing
• Molding
• Oil &Gas
• Power Generation
• Vehicle Assembly Facilities
Features/Benefits:
• Pressures up to 3,000 PSI
• 5 mounting sizes with flows up to 40 GPM
• Needle and poppet are stainless steel
• Set screw or optional finger screw locks needle flow position
Applications:
• Suitable for general hydraulic applications
Read More...The FS series flow control valve comes in 5 sizes ranging from 5 to 40 GPM.
Markets:
• Factory Automation
• Machine Tools
• Marine
• Material Handling
• Mining
• Miscellaneous Industrial
• Miscellaneous Manufacturing
• Molding
• Oil &Gas
• Power Generation
• Vehicle Assembly Facilities
Features/Benefits:
• Pressures up to 3,000 PSI
• 5 mounting sizes with flows up to 40 GPM
• Needle and poppet are stainless steel
• Set screw or optional finger screw locks needle flow position
Applications:
• Suitable for general hydraulic applications
| Action | Part No. | Availability | Partner Available | Price | UOM | Connection Type | Seal Material | Actuation Type | Function | Weight | Maximum Flow Rate | Body Material | Division | Maximum Operating Pressure | Minimum Operating Temperature | Needle Type | Flow Rate | Connection Size | Configuration | Maximum Operating Temperature | Cracking Pressure | Maximum Operating Pressure | Size | Maximum Flow Rate | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FS1200S | Quote Required | $3,354.00/each | EA | Subplate mounting | Nitrile | Manual | Flow Control | 1.17 kg | 25 Gal/min | Steel | Hydraulic Valve Systems Division | 3000 psi | n/a | Standard | n/a | 3/4 inch | n/a | n/a | 5 psi | 3000 PSI | 3/4" | 25 GPM | Subplate | ||
| FS1600S | Quote Required | $7,023.75/each | EA | Subplate mounting | Nitrile | Manual | Flow Control | 2.31 kg | 40 Gal/min | Steel | Hydraulic Valve Systems Division | 3000 psi | n/a | Standard | n/a | 1 inch | n/a | n/a | 5 psi | 3000 PSI | 1" | 40 GPM | Subplate | ||
| FS400S | Quote Required | $1,736.25/each | EA | Subplate mounting | Nitrile | Manual | Flow Control | 0.23 kg | 5 Gal/min | Steel | Hydraulic Valve Systems Division | 3000 psi | n/a | Standard | n/a | 1/4 inch | n/a | n/a | 5 psi | 3000 PSI | 1/4" | 5 GPM | Subplate | ||
| FS400S4 | Quote Required | $1,810.50/each | EA | Subplate mounting | Nitrile | Manual | Flow Control | 0.23 kg | 5 Gal/min | Steel | Hydraulic Valve Systems Division | 3000 psi | n/a | Micro-Fine | n/a | 1/4 inch | n/a | n/a | 5 psi | 3000 PSI | 1/4" | 5 GPM | Subplate | ||
| FS600S | Quote Required | $2,185.50/each | EA | Subplate mounting | Nitrile | Manual | Flow Control | 8 Gal/min | Steel | Hydraulic Valve Systems Division | 3000 psi | n/a | Standard | n/a | 3/8 inch | n/a | n/a | 5 psi | 3000 PSI | 3/8" | 8 GPM | Subplate |
