Parker FS1600S - Flow Control, Subplate Mounted Valve – FS Series

Parker’s FS series flow control valve offers superior construction and high versatility due to its variety of materials, sizes and port styles. It can be used in both the mobile and industrial markets.

AFP Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. FS1600S

$7,023.75/each

Products specifications

Attribute name	Attribute value
Body Material	Steel	Maximum Operating Temperature	N/A
Needle Type	Standard	Flow Rate	N/A
Maximum Flow Rate	40 Gal/min	Minimum Operating Temperature	N/A
Weight	2.31 kg	Maximum Operating Pressure	3000 psi
Actuation Type	Manual	Connection Size	1 inch
Seal Material	Nitrile	Connection Type	Subplate mounting
Division	Hydraulic Valve Systems Division	Configuration	N/A
Function	Flow Control	Cracking Pressure	5 psi
Maximum Operating Pressure	3000 PSI	Size	1"
Maximum Flow Rate	40 GPM	Mounting Type	Subplate

Product resources

Literature and Reference Materials

CATALOGUE - Throttle Check Valve Series FS (Europe and Asia) (PDF)
