Relief Valves - 134 Series
*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.
AFP Industries stocks this Parker series for quote or purchase, with interchange support and southeast warehouse availability.
The 134 series is a diaphragm type relief valve that relieves excess pressure, thus protecting the pneumatic circuit or system. This compact, sensitive diaphragm-type relief valve can be used where gradual proportional relief is required. It contains a top adjustment knob that adjusts relief range, same as a miniature regulator. There are four spring ranges (0-15, 0-25, 0-50 and 0-100 PSIG) available. The 134 has a brass body with captured exhaust and is an inline type unit with 3 inlet ports and 1 outlet port.
Markets:
• Factory Automation
• Heavy Industries
Features/Benefits:
• Compact design saves space
• Top adjustment knob
• Durable brass body
• Protects pneumatic circuit or system
Applications:
• Industrial environment
• General pneumatic assembly
| Action | Part No. | Availability | Partner Available | Price | UOM | Maximum Inlet Pressure Rating | Adjustment Mechanism | Division | Pressure Relief Setting | Port Size | Body Material | Operating Temperature | Adjustment Screw Material | Port Type | Available Accessories | Pressure Relief Setting (psig) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 134-02A | Quote Required | $36.34/each | EA | 300 psig | Polypropylene Push-Pull Locking Knob | Pneumatic Division | 0 to 6.9 barg | Inlet Port 1/8" and 1/4", Outlet Port 1/4" | Brass | +4° to +49° °C | Zinc Plated Steel Adjusting Screw and Spring | 3 Female Inlet Ports, and 1 outlet port<br>NPT │ BSPP | W/O panel mount nut | 0-25 | ||
| 134-02AAP | Quote Required | $42.25/each | EA | 20.7 barg | Polypropylene Push-Pull Locking Knob | Pneumatic Division | 0 to 100 psig | Inlet Port 1/8" and 1/4", Outlet Port 1/4" | Brass | +4° to +49° °C | Zinc Plated Steel Adjusting Screw and Spring | 3 Female Inlet Ports, and 1 outlet port<br>NPT │ BSPP | With panel mount nut | 0-15 | ||
| 134-02AP | Quote Required | $39.12/each | EA | 300 psig | Polypropylene Push-Pull Locking Knob | Pneumatic Division | 0 to 6.9 barg | Inlet Port 1/8" and 1/4", Outlet Port 1/4" | Brass | +4° to +49° °C | Zinc Plated Steel Adjusting Screw and Spring | 3 Female Inlet Ports, and 1 outlet port<br>NPT │ BSPP | With panel mount nut | 0-25 | ||
| 134-02B | Quote Required | $36.34/each | EA | 20.7 barg | Polypropylene Push-Pull Locking Knob | Pneumatic Division | 0 to 100 psig | Inlet Port 1/8" and 1/4", Outlet Port 1/4" | Brass | +40° to +120° °F | Zinc Plated Steel Adjusting Screw and Spring | 3 Female Inlet Ports, and 1 outlet port<br>NPT │ BSPP | W/O panel mount nut | 0-50 | ||
| 134-02BP | Quote Required | $39.12/each | EA | 300 psig | Polypropylene Push-Pull Locking Knob | Pneumatic Division | 0 to 6.9 barg | Inlet Port 1/8" and 1/4", Outlet Port 1/4" | Brass | +40° to +120° °F | Zinc Plated Steel Adjusting Screw and Spring | 3 Female Inlet Ports, and 1 outlet port<br>NPT │ BSPP | With panel mount nut | 0-50 | ||
| 134-02C | Quote Required | $36.34/each | EA | 300 | Polypropylene Push-Pull Locking Knob | Pneumatic Division | 0 to 100 | 1/8 inch (inlet port) | Brass | 40 to 120 | Steel, Zinc-plated (adjusting screw and spring) | 3 Female Inlet Ports, and 1 outlet port<br>NPT │ BSPP | W/O panel mount nut | 0-100 | ||
| 134-02CP | Quote Required | 88 In Stock | $39.12/each | EA | 300 psig | Polypropylene Push-Pull Locking Knob | Pneumatic Division | 0 to 6.9 barg | Inlet Port 1/8" and 1/4", Outlet Port 1/4" | Brass | +40° to +120° °F | Zinc Plated Steel Adjusting Screw and Spring | 3 Female Inlet Ports, and 1 outlet port<br>NPT │ BSPP | With panel mount nut | 0-100 |
