Parker VR02 V1200US-SF - Transair® Valves for Aluminum Pipe

Transair® Valves are designed for quick and easy integration into a Transair compressed air piping system. Placing valves at strategic points allows for easy system isolation.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. VR02 V1200US-SF

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Specifications Met	ASME B31.1 - 31.3	Maximum Operating Temperature	85 °C
Industry	General Industrial	Application	In Plant Pneumatic
Technology	Fluid & Gas Handling	Brand	Parker
Operation Type	Manual	Vacuum Pressure Rating	0.03 inch-Hg
Assembly Time	0.38 Hours	Product Style	Butterfly Valve
For Fluid Type	Vaccum	Seat Material	NBR
Weight	17.009 kg	Response Time	n/a
Function	2-Way	Division	Fluid System Connectors Division
Actuation Type	Manual	Quantity per Box	1
Connection 1 Size	8 inch	Orifice Size	220 mm
Seal Material	NBR	Connection 1 Type	Flange
Body Material	Treated Steel	Configuration	Pipe to Flange
Division	Fluid System Connectors Division	Minimum Operating Temperature	-4 °F
Maximum Operating Pressure	10 bar 150 PSI (-4° to +140°F)/10 bar (-20°C to 60°C) For Canada, Please refer to https://www.parker.com/ca/en/crn/transair.html	Connection 2 Size	8 inch
Product Type	Flow Control Valve	Mounting Type	Flanged
Flow Direction	Bidirectional	Options	Lockable
Connection 2 Type	Flange	Pipe O.D. (mm)	220
Silicone Free	Yes	Vented	No
Connection Thread Size (inch)	n/a	Style	Butterfly Valve
Pipe O.D. (inch)	8
