Parker VR02 L1 00 - Transair® Valves for Aluminum Pipe

Transair® Valves are designed for quick and easy integration into a Transair compressed air piping system. Placing valves at strategic points allows for easy system isolation.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. VR02 L1 00

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Application	In Plant Pneumatic	Industry	General Industrial
Technology	Fluid & Gas Handling	Connection 2 Size	3 inch
Division	Low Pressure Connectors Europe Division	Product Style	Butterfly Valve
Operation Type	Manual	Brand	Parker
Actuation Type	Manual	Seat Material	NBR
Connection 1 Size	76 mm	Vacuum Pressure Rating	1 mbar
Body Material	Cast Iron	Maximum Operating Pressure	16 bar 232 PSI (-4°F to +113°F)/16 bar (-20°C to 45°C) up to 100 mm 188 PSI (-4° to +140°F)/13 bar (-20°C to 60°C) up to 168 mm 101 PSI (-4° to +185°F)/7 bar ( -20°C to 85°C) up to 168 mm For Canada, Please refer to https://www.parker.com/ca
Response Time	n/a	Function	2-Way
Seal Material	NBR	Orifice Size	76 mm
Assembly Time	0.13 Hours	For Fluid Type	Inert Gases
Quantity per Box	1	Configuration	Pipe to Flange
Minimum Operating Temperature	-20 °C	Connection 1 Type	Flange
Mounting Type	Flanged	Product Type	Flow Control Valve
Connection 2 Type	Flange	Specifications Met	TUV
Options	Lockable	Weight	7.054 lb
Division	Low Pressure Connectors Europe Division	Flow Direction	Bidirectional
Maximum Operating Temperature	185 °F	Pipe O.D. (mm)	76
Vented	No	Silicone Free	Yes
Pipe O.D. (inch)	6	Connection Thread Size (inch)	n/a
Style	Butterfly Valve

Product resources

Compliance, Certifications & Safety

Transair Regulations & Certifications (PDF)

Literature and Reference Materials
