Parker NS-1002-16FP - Non-Spill, Flat Face, Push to Connect Quick Couplings with Sleeve Lock - NS Series

Name: Parker NS-1002-16FP - Non-Spill, Flat Face, Push to Connect Quick Couplings with Sleeve Lock - NS Series
SKU: NS-1002-16FP
Price: 126.13 USD
Availability: InStock

Parker's non-spill, flat face hydraulic couplers are ideal for use across a variety of hydraulic applications where fluid lines require fast and easy connection and disconnection with minimal spillage and limited air inclusion.

AFP Availability:

1 Limited Stock

Richmond, VA

1 (Pickup only)

Partner Available:

6 In Stock

Quantities sourced from Partner Network may incur an upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

Brand Parker

Part No. NS-1002-16FP

$126.13/each

Qty:

Products specifications

Attribute name	Attribute value
UOM	EA	Seal Material	Nitrile
Maximum Operating Pressure	2500 psi	Minimum Operating Temperature	-40 °F
Plating Type	Zinc with Clear Trivalent Chromate	Product Type	Push to Connect
Flow Rate	50 Gal/min	Application	Hydraulics
Body Material	Steel	Hex Size	1.62 inch
Dimensional Weight	0.12464028776978417 lb	Valve Type	Non-spill
Maximum Operating Temperature	250 °F	Division	Quick Coupling Division
Connection Thread Size (inch)	1 - 11 1/2	Coupling Half	Male Nipple
Body Size (inch)	1	Connection Type	Female NPSF

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories (PDF)

Literature and Reference Materials
