Parker CM2AAFN - CHECK SANDWICH VALVE - CM SERIES

Parker’s CM series check valves is an integral, full flow check valve.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. CM2AAFN

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Media	Oil	Division	Hydraulic Valve Systems Division
Mounting Type	Subplate	Maximum Operating Temperature	+140
Size	NFPA D03	Port Connection	A Port Inverted
Maximum Operating Pressure	5000	Actuation Type	Hydraulic Pressure
Weight	1.7	Cracking Pressure	5
Product Style	Sandwich Check Valve	Seal Material	Nitrile
Maximum Flow Rate	20	Body Material	Steel
Minimum Operating Temperature	-4	Maximum Flow Rate	20 GPM
Mounting Type	Subplate	Size	NFPA D03; CETOP 3; NG6
Maximum Operating Pressure	5000 PSI
