Parker 797ST-12 - Hydraulic Constant Working Pressure Hose 6000 PSI - GlobalCore 797 Hose

Part of the GlobalCore line of robust yet lightweight hydraulic hose, Parker’s 797 hose is an easy-to-bend, easier-to-install 6000 PSI constant working pressure hose.
AFP Availability:
6 In Stock
Summerville, SC6
Partner Available:626 In Stock
Quantities sourced from Partner Network may incur an upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.
Brand Parker
Part No. 797ST-12
$60.63/foot
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Parker’s 797 hose, within the GlobalCore product line, was designed to deliver consistency and reliability with a constant working pressure of 6,000 PSI in all sizes. The 797 hose is made with Compact Spiral technology making it light, durable, and easily bent making installation easier and quicker. The 797 hose is designed, built and tested to the ISO 18752 performance specifications. Sizes range from ¼” to 2” in diameter with different cover options available for various markets.

Markets:
• Military
• Construction
• Forestry
• Oil Field Service
• Industrial
• Mining

Features/Benefits:
• Standard, ToughCover or SuperTough cover options to prevent abrasion
• Half SAE bend radius for ease of installation and low force to flex
• 30% smaller O.D. compared to standard SAE spiral hose
• 6,000 PSI constant working pressure in all sizes
• Less hose weight than SAE spiral
• Twice the impulse/life for a longer useful life of the hose
• Flex impulse tested to provide a superior hose in both performance and service life

Applications:
• Petroleum base hydraulic fluids and lubricating oils

Compatible Fittings:
• 43 series fittings (for -4 to -6)
• 77 series fittings (for -8 to -32)
Products specifications
Attribute nameAttribute value
UOMFTApplicationLubricating Oils
Cover MaterialSynthetic Rubber Abrasion ResistantNominal Hose Inside Diameter19 mm
Minimum Operating Temperature-40 °CWeight1.16 kg/m
Maximum Operating Pressure42 MPaMinimum Bend Radius5-1/4 inch
Specifications MetISO 18752, Type DCHose Reinforcement Material4 or 6 Spirals of Steel Wire
DivisionHose Products DivisionOutside Diameter1.1 inch
Inside Diameter3/4 inchHose Inner Tube MaterialProprietary Synthetic Rubber Compound
MediaLubricantsCompatible Fitting77 Series
Size-12Maximum Operating Temperature257 °F
Hose I.D. (size)-12Hose Cover TypeSuperTough
