Parker 7181-1001 - Heavy Duty Heater Hose, Series 7181

Heavy Duty Heater Hose is designed for use in heater and radiator systems in vehicles and industrial equipment in applications to 257°F and 65 psi, Series 7181

AFP Availability:	Quote Required
Partner Available:	2269 In Stock

Brand Parker

Part No. 7181-1001

$3.70/foot

Products specifications

Attribute name	Attribute value
UOM	FT	Weight	0.37 lb/ft
Maximum Operating Pressure	3.1 bar	Specifications Met	SAE J20R3EC, Class D2
Hose Reinforcement Material	2 Plies of Textile	Minimum Bend Radius	12 inch
Division	Hose Products Division	Cover Color	Black
Inside Diameter	1 inch	Outside Diameter	1.340 inch
Compatible Fitting	n/a	Package Type	Reel
Media	Water (Hot Water)	Hose Inner Tube Material	Black
Maximum Operating Temperature	125 °C	Application	Specialty
Cover Material	Ethylene Propylene Diene Monomer (EPDM)	Minimum Operating Temperature	-40 °C
Maximum Working Pressure (psi)	45	Hose I.D. (inch)	1
Standard Pack Qty (ft)	300
