Parker 3C20EF-EF65 - Soft Seat, In Line Hydraulic Check Valves - S6C and 3C Series

Parker's, in line check valves are one way flow control devices used primarily in hydraulic systems to eliminate potential damage caused by fluid back pressure.

AFP Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 3C20EF-EF65

$305.16/each

Products specifications

Attribute name	Attribute value
Maximum Flow Rate	90 Gal/min	Body Material	Steel
Mounting Type	Threaded	Minimum Operating Temperature	400 °F
Connection Type	Female SAE ORB to Female SAE ORB	Division	Quick Coupling Division
Maximum Operating Temperature	-40 °F	Flow Direction	n/a
Configuration	n/a	Actuation Type	Mechanical
Seat Type	Soft Seat	Maximum Operating Pressure	3000 psi
Connection Size	1-5/8"-12 UN inch	Seal Material	Fluorocarbon
Body Size (inch)	1 1/4	Inlet Port Size (inch)	1 5/8 - 12 UN
Cracking Pressure (psi)	65	Outlet Port Size (inch)	1 5/8 - 12 UN
Inlet Port Connection Type	Female SAE Straight Thread	Outlet Port Connection Type	Female SAE Straight Thread
