Parker 1120-4A-BLK-100 - Nylon Air Brake Tubing

Name: Parker 1120-4A-BLK-100 - Nylon Air Brake Tubing
SKU: 1120-4A-BLK-100
Price: 1.24 USD
Availability: InStock

Parflex makes enough air brake tubing a year to circle the globe twice. Brake Line tubing provides excellent kink resistance. This means reduced, and or, eliminated kinked lines resulting in less rework at installation on semi-truck air lines.

AFP Availability:

2554 In Stock

Richmond, VA	1,233
Norfolk, VA	278
Grovetown, GA	200
Knoxville, TN	180
Summerville, SC	134
Jacksonville, FL	108
Fayetteville, NC	100
Knoxville, TN	90
Ashland, VA	80 (Pickup only)
Johnson City, TN	61 (Pickup only)
Richmond, VA	50 (Pickup only)
Mooresville, NC	40

Partner Available:

1541 In Stock

Quantities sourced from Partner Network may incur an upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

Brand Parker

Part No. 1120-4A-BLK-100

$1.24/each

Qty:

Products specifications

Attribute name	Attribute value
Tube Inside Diameter	0.17 inch	Division	Parflex Division
Cover Color	n/a	Minimum Bend Radius	25.4 mm
Tube Outside Diameter	6.4 mm	Specifications Met	SAE J844
Tube Material	Polyamide (PA)	Maximum Operating Pressure	10.3 bar
Color	Black	Weight	0.012 lb/ft
Minimum Operating Temperature	-40 °F	Application	Air Brake
Cover Material	n/a	Size	-4
Minimum Burst Pressure	82.7 bar	Maximum Operating Temperature	200 °F
Compatible Fitting	PTC	Media	Air
Tube O.D. (inch)	1/4	Color	Black
Standard Pack Qty (ft)	100 ft box
