Silicone Greek Corrugated High Temperature Wire Reinforced Coolant Hose, Series 6621
*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.
Parker's Series 6621 Silicone Greek Corrugated High Temperature Wire Reinforced Coolant Hose provides excellent service across a wide variety of coolants and multiple engine heater and radiator applications. The silicone construction resists chemicals, aging, cold leaks, cracking, delamination, heat, ozone and peeling to maximize performance. The Greek corrugated construction provides superior flexibility for easy routing and installation, resists the elevated temperatures common to engine compartments and is available in long continuous lengths for maximum versatility.
Markets:
• General Industrial
• Transportation
Features/Benefits:
• Tube: Black silicone for superior heat resistance to 392°F.
• Reinforcement: Multiple textile plies for strength and durability, and a wire helix for full suction capability and a path to conduct a static charge to ground.
• Cover: Red silicone Greek corrugated for superior flexibility, temperature resistance and easy identification.
Applications:
- media
• Coolant
• Hot water
- usage
• Coolant transfer in heater and coolant circuits
• Agricultural equipment
• Buses
• Construction equipment
• Off-road equipment
• Trucks
Industry Standards:
• SAE J20R2 Class A performance
• TMC RP303B
Safety/Technical:
• Design Factor: 3:1
| Action | Part No. | Availability | Partner Available | Price | UOM | Division | Inside Diameter | Weight | Package Type | Cover Color | Hose Inner Tube Material | Application | Media | Outside Diameter | Specifications Met | Vacuum Pressure Rating | Maximum Operating Pressure | Maximum Operating Temperature | Minimum Operating Temperature | Design Factor | Cover Material | Cover Structure | Minimum Bend Radius | Minimum Burst Pressure | Hose Reinforcement Material | Hose I.D. (inch) | Standard Pack Qty (ft) | Minimum Burst Pressure (psi) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6621-0500025 | Quote Required | TBD | Hose Products Division | 1/2 | 0.20 | Coil | Red | Black | Engine | Coolants | 0.910 | ISO 1307.0 | 17.7 | 5 | 392 | -76 | 3:1 | Silicone | Greek-Corrugated | 1.2 | 225 | Multiple Plies of High Temperature Textile with Wire Helix | 1/2 | 25 | 225 | |||
| 6621-0500130 | Quote Required | TBD | Hose Products Division | 1/2 inch | 0.09 kg | Coil | Red | Black | Engine | Coolants | 23 mm | ISO 1307.0 | 17.7 Inch-Hg | 5 bar | 200 °C | -76 °F | 3:1 | Silicone | Glossy | 1.2 inch | 15.5 bar | Multiple Plies of High Temperature Textile with Wire Helix | 1/2 | 130 | 225 | |||
| 6621-0625025 | Quote Required | TBD | Hose Products Division | 5/8 | 0.22 | Coil | Red | Black | Engine | Coolants | 1.020 | ISO 1307.0 | 17.7 | 5 | 392 | -76 | 3:1 | Silicone | Greek-Corrugated | 1.4 | 225 | Multiple Plies of High Temperature Textile with Wire Helix | 5/8 | 25 | 225 | |||
| 6621-0625130 | Quote Required | TBD | Hose Products Division | 16 mm | 0.22 lb | Coil | Red | Silicone | Silicone Coolant | Coolants | 1.020 inch | SAE J20R1, Class A | 17.7 Inch-Hg | 75 psi | 200 °C | -60 °C | 3:1 | Silicone | Greek-Corrugated | 35.1 mm | 225 psi | Multiple Plies of High Temperature Textile with Wire Helix | 5/8 | 130 | 225 | |||
| 6621-0750025 | Quote Required | TBD | Hose Products Division | 3/4 | 0.24 | Coil | Red | Black | Engine | Coolants | 1.140 | ISO 1307.0 | 17.7 | 5 | 392 | -76 | 3:1 | Silicone | Greek-Corrugated | 1.8 | 225 | Multiple Plies of High Temperature Textile with Wire Helix | 3/4 | 25 | 225 | |||
| 6621-0750130 | Quote Required | TBD | Hose Products Division | 3/4 inch | 0.24 lb | Coil | Red | Black | Silicone Coolant | Water | 1.140 inch | ISO 1307.0 | 17.7 Inch-Hg | 5 bar | 392 °F | -76 °F | 3:1 | Silicone | Glossy | 45 mm | 225 psi | Multiple Plies of High Temperature Textile with Wire Helix | 3/4 | 130 | 225 | |||
| 6621-1000025 | Quote Required | 148 In Stock | $49.31 | FT | Hose Products Division | 25 mm | 0.14 kg | Coil | Red | Silicone | Engine | Water | 35 mm | SAE J20R1, Class A | 17.7 Inch-Hg | 5 bar | 392 °F | -60 °C | 3:1 | Silicone | Glossy | 50 mm | 225 psi | Multiple Plies of High Temperature Textile with Wire Helix | 1 | 25 | 225 | |
| 6621-1000130 | Quote Required | TBD | Hose Products Division | 1 inch | 0.14 kg | Coil | Red | Silicone | Silicone Coolant | Water | 35 mm | SAE J20R1, Class A | 17.7 Inch-Hg | 75 psi | 200 °C | -60 °C | 3:1 | Silicone | Glossy | 50 mm | 225 psi | Multiple Plies of High Temperature Textile with Wire Helix | 1 | 130 | 225 | |||
| 6621-1250025 | Quote Required | TBD | Hose Products Division | 1-1/4 inch | 0.18 kg | Coil | Red | Black | Engine | Coolants | 1.690 inch | ISO 1307.0 | 17.7 Inch-Hg | 5 bar | 392 °F | -76 °F | 3:1 | Silicone | Glossy | 80 mm | 225 psi | Multiple Plies of High Temperature Textile with Wire Helix | 1-1/4 | 25 | 225 | |||
| 6621-1375025 | Quote Required | TBD | Hose Products Division | 1-3/8 | 0.43 | Coil | Red | Black | Engine | Coolants | 1.890 | ISO 1307.0 | 17.7 | 5 | 392 | -76 | 3:1 | Silicone | Greek-Corrugated | 3.7 | 225 | Multiple Plies of High Temperature Textile with Wire Helix | 1-3/8 | 25 | 225 | |||
| 6621-1500025 | Quote Required | TBD | Hose Products Division | 1-1/2 inch | 0.21 kg | Coil | Red | Silicone | Silicone Coolant | Coolants | 1.930 inch | ISO 1307.0 | 17.7 Inch-Hg | 75 psi | 200 °C | -60 °C | 3:1 | Silicone | Greek-Corrugated | 3.9 inch | 15.5 bar | Multiple Plies of High Temperature Textile with Wire Helix | 1-1/2 | 25 | 225 | |||
| 6621-1750025 | Quote Required | TBD | Hose Products Division | 1-3/4 inch | 0.24 kg | Coil | Red | Silicone | Silicone Coolant | Coolants | 2.210 inch | SAE J20R1, Class A | 17.7 Inch-Hg | 5 bar | 200 °C | -60 °C | 3:1 | Silicone | Greek-Corrugated | 130 mm | 225 psi | Multiple Plies of High Temperature Textile with Wire Helix | 1-3/4 | 25 | 225 | |||
| 6621-2000025 | Quote Required | TBD | Hose Products Division | 51 mm | 0.88 lb | Coil | Red | Silicone | Silicone Coolant | Water | 64 mm | SAE J20R1, Class A | 17.7 Inch-Hg | 5 bar | 392 °F | -76 °F | 3:1 | Silicone | Greek-Corrugated | 150.1 mm | 225 psi | Multiple Plies of High Temperature Textile with Wire Helix | 2 | 25 | 225 |
