Parker VR01 L3 00 - Transair® Valves for Aluminum Pipe

Transair® Valves are designed for quick and easy integration into a Transair compressed air piping system. Placing valves at strategic points allows for easy system isolation.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. VR01 L3 00

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
For Fluid Type	Compressed Air	Body Material	Treated Ductile Iron
Assembly Time	0.15 Hours	Response Time	n/a
Weight	40.785 lb	Connection 2 Size	4 inch
Function	2-Way	Actuation Type	Manual
Vacuum Pressure Rating	1 mbar	Options	Standard
Connection 1 Size	100 mm	Seat Material	PTFE
Specifications Met	TUV	Connection 1 Type	Flange
Quantity per Box	1	Seal Material	PTFE
Configuration	Pipe to Flange	Product Type	Flow Control Valve
Operation Type	Manual	Orifice Size	4 inch
Minimum Operating Temperature	-4 °F	Division	Low Pressure Connectors Europe Division
Flow Direction	Bidirectional	Mounting Type	Flanged
Connection 2 Type	Flange	Application	In Plant Pneumatic
Maximum Operating Temperature	85 °C	Product Style	Ball Valve
Division	Fluid System Connectors Division	Brand	Parker
Industry	General Industrial	Maximum Operating Pressure	232 psi
Technology	Fluid & Gas Handling	Pipe O.D. (inch)	4
Pipe O.D. (mm)	101	Style	Ball Valve
Silicone Free	Yes	Connection Thread Size (inch)	n/a
Vented	No
