Parker VR01 L3 00 46 - Transair® Valves for Aluminum Pipe

Transair® Valves are designed for quick and easy integration into a Transair compressed air piping system. Placing valves at strategic points allows for easy system isolation.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. VR01 L3 00 46

$828.47

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Mounting Type	Flanged
Product Type	Flow Control Valve	Connection 1 Size	4 inch
Minimum Operating Temperature	-4 °F	Connection 2 Type	Flange
Weight	40.780 lb	Flow Direction	Bidirectional
Application	In Plant Pneumatic	Industry	General Industrial
Maximum Operating Temperature	85 °C	Technology	Fluid & Gas Handling
Maximum Operating Pressure	232 psi	Operation Type	Manual
Vacuum Pressure Rating	0.03 inch-Hg	Actuation Type	Manual
Body Material	Treated Ductile Iron	Response Time	n/a
Brand	Transair	Connection 2 Size	4 inch
Specifications Met	CE	Assembly Time	0.15 Hours
Division	Fluid System Connectors Division	Product Style	Ball Valve
Orifice Size	100 mm	Function	2-Way
Seal Material	PTFE	For Fluid Type	Inert Gases
Quantity per Box	1	Options	Standard
Seat Material	PTFE	Configuration	Pipe to Flange
Connection 1 Type	Flange	Division	Fluid System Connectors Division
Style	Ball Valve	Vented	No
Silicone Free	Yes	Connection Thread Size (inch)	n/a
Pipe O.D. (inch)	4	Pipe O.D. (mm)	101
