Parker VC-001 - Refrigeration Access Valves

Parker's access valves offer low cost access ports for refrigeration service. All fittings feature 1/4" SAE male flare access ports and are furnished with a finger tight quick seal cap.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. VC-001

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Specifications Met	Valve Core Meets ARI Standard 720	Division	Fluid System Connectors Division
Body Material	Brass	Media	Fluorocarbon Refrigerants
Maximum Operating Temperature	220 °F	Nut Material	Brass
Minimum Operating Temperature	-20 °F	Maximum Operating Pressure	34 bar
Shape	Valve Core	Connection 1 Style	SAE Male Flare
Style	na	Connection 2 Tube O.D. (inch)	na
Connection 2 Solder O.D. (inch)	na	Connection 2 Thread Size (inch)	na
Connection 1 Tube O.D. (inch)	1/4	Connection 2 Style	na
