Parker ULC-324FF3FF-000 - Ultra Low Carryover Valve

Parker's Ultra Low Carryover Valve features best-in-class carryover performance and the ability to reduce fluidic circuit complexity.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. ULC-324FF3FF-000

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Weight Unit of Measure	lbs	Height	0.65" (16.5 mm)
Division	Precision Fluidics Division	Valve Type	3 Port 4 Mode
Industry	Clinical Diagnostics, Analytical Chemistry	Cycles per Lifetime	10 Million Cycles
Max Order Quantity	9	Out of Stock Lead Time	20
Application	Sampling, Reagent Addition, Flow Control, Proportioning	Shipping Weight	0.25
Width	0.65" (16.5 mm)	Internal Leak Rate	0.15 sccm of Air
Flow Coefficient	0.011	Coil Power Consumption	3.0 Watts per coil
Product Weight	0.0956	Response Time	< 10 msec
Standard Lead Time	5	Weight	1.06 oz (30.2 g)
Pressure Rating	45 psig (3.1 bar)	Body Material	PEEK
Flow Rate	Up to 320 mL/min	Electrical Connection	4.5" (114 mm) leads with Molex connector
Orifice Size	0.03" (0.76 mm)	Length	1.48" (37.6 mm)
Valve Configuration	3 Port	Fluid Port Connection	Face Seal
Input Voltage	24V	Seal Material	FFKM
