Parker RR04 N7 01 - Transair® Fittings for Stainless Steel Pipe

Transair Fittings for Stainless Steel Pipe are quick and easy to install. Available in EPDM and FKM seals for maximum chemical compatibility.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. RR04 N7 01

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Shape	Tee	Weight	0.46 lb
Assembly Time	0.06 Hours	Connection 1 Type	Pipe
Minimum Operating Temperature	-4 °F	Division	Low Pressure Connectors Europe Division
Connection 2 Type	Pipe	Seal Material	EPDM
Product Style	Tee	Pipe Outside Diameter	22 mm
Vacuum Pressure Rating	0.03 inch-Hg	Product Type	Tee
Connection 2 Size	3/4 inch	Maximum Operating Temperature	90 °C
Connection 3 Type	Pipe	Configuration	Pipe to Pipe
Connection 3 Size	3/4 inch	Division	Fluid System Connectors Division
Connection 1 Size	3/4 inch	Brand	Transair
Maximum Operating Pressure	10 bar	Application	Vacuum
Quantity per Box	5.0	Shape	Equal Tee
Seal Material	EPDM	Pipe O.D. 2 (inch)	N/A
Pipe O.D. (mm)	22	Pipe O.D. (inch)	3/4
Connection Thread Size (inch)	n/a	Pipe O.D. 2 (mm)	N/A

Product resources

Compliance, Certifications & Safety

Transair Regulations & Certifications (PDF)

Literature and Reference Materials

Transair Master Catalog (PDF)

Selector Guides

Transair Chemical Compatibility Chart for Stainless Steel Pipe (PDF)
