Parker RR02 N7 01 - Transair® Fittings for Stainless Steel Pipe

Transair Fittings for Stainless Steel Pipe are quick and easy to install. Available in EPDM and FKM seals for maximum chemical compatibility.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. RR02 N7 01

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Pipe Outside Diameter	3/4 inch	Seal Material	EPDM
Minimum Operating Temperature	-4 °F	Connection 2 Size	22 mm
Weight	0.36 lb	Maximum Operating Pressure	145 psi
Assembly Time	0.04 Hours	Application	Process Water
Shape	Elbow 90°	Connection 1 Size	3/4 inch
Division	Fluid System Connectors Division	Configuration	Pipe to Pipe
Product Style	Elbow	Vacuum Pressure Rating	1 mbar
Quantity per Box	5.0	Brand	Transair
Division	Fluid System Connectors Division	Connection 1 Type	Pipe
Maximum Operating Temperature	194 °F	Connection 2 Type	Pipe
Product Type	Elbow	Pipe O.D. (inch)	3/4
Connection Thread Size (inch)	n/a	Pipe O.D. 2 (mm)	N/A
Seal Material	EPDM	Shape	90° Elbow
Pipe O.D. (mm)	22	Pipe O.D. 2 (inch)	N/A

Product resources

Compliance, Certifications & Safety

Transair Regulations & Certifications (PDF)

Literature and Reference Materials

Transair Master Catalog (PDF)

Selector Guides

Transair Chemical Compatibility Chart for Stainless Steel Pipe (PDF)
