Parker PDP341 - Connect Under Pressure, Test Port, Diagnostic Quick Couplings - PDP Series

Name: Parker PDP341 - Connect Under Pressure, Test Port, Diagnostic Quick Couplings - PDP Series
SKU: PDP341
Price: 89.02 USD
Availability: InStock

Parker's diagnostic quick couplers and test point nipples provide easy connections for mechanical gauges or specialized diagnostic equipment including Parker's SensoControl meters and accessories.

AFP Availability:

1 Limited Stock

Greensboro, NC

Partner Available:

22 In Stock

Quantities sourced from Partner Network may incur an upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

Brand Parker

Part No. PDP341

$89.02/each

Qty:

Products specifications

Attribute name	Attribute value
UOM	EA	Hex Size	0.69 inch
Body Material	Steel	Division	Quick Coupling Division
Valve Type	Ball	Maximum Operating Temperature	250 °F
Maximum Operating Pressure	6000 psi	Seal Material	Nitrile
Minimum Operating Temperature	-40 °F	Plating Type	Zinc with clear trivalent chromate
Application	Diagnostic	Product Type	Push to connect
Body Size	1/8 inch	Connection Type	Male ORB
Connection Thread Size (inch)	7/16 - 20	Coupling Half	Male Nipple
Tube Size (inch)	na

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories (PDF)

Literature and Reference Materials
