Parker NSS-501-12HB - High Flow, Liquid Cooling, Flat Face Hydraulic Quick Connect Couplings - NSS Series

Quick connect, flat face hydraulic couplers for liquid cooling and thermal management applications for electronics, servers and supercomputers. Their compact body size and guided alignment save time and frustration when connecting fluid lines.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. NSS-501-12HB

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Hex Size	1.25 inch	Product Type	Push-to-Connect
Maximum Operating Pressure	300 psi	Connection Type	Hose Barb
Body Material	Stainless Steel	Valve Type	Flat Face
Maximum Operating Temperature	250.0 °F	Division	Quick Coupling Division
Seal Material	EPDM	Minimum Operating Temperature	-70.0 °F
Flow Rate	12 Gal/min	Application	Liquid Cooling
Body Size (inch)	1/2	Coupling Half	Female Coupler
Connection Thread Size (inch)	na	Hose I.D.	3/4
