| Actuation Type | Electrical | Maximum Operating Pressure | 3000 psi |
| Seal Material | Nitrile | Connection Size | n/a |
| Connection Type | n/a | Body Material | n/a |
| Division | Hydraulic Systems Division | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Minimum Operating Temperature | -34 °C | Override Functionality | n/a |
| Operation Type | Solenoid Operated | Installation Torque | 30 Nm |
| Coil Nut Tightening Torque | 3 lb-ft | Flow Rate | 60 L/min |
| Maximum Flow Rate | 16 Gal/min | Maximum Inlet Pressure Rating | 210 bar |
| Maximum Operating Temperature | +121 °C | Function | Proportional Flow Control/Regulator |
| Frequency | 100-400 Hz | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Valve Material | All parts steel. All operating parts hardened steel | Operating Temperature | -30 to +250 °F |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Configuration | Normally Closed, Pressure Compensated |
| Flow Direction | Inlet port 3, Bypass port 2, Regulated port 4 | Coil Type | 5/8" Super Coil |
| Weight | 0.31 lb | Power Consumption | 18, 28 W |
| Minimum Pressure Differential | 13.8, 20.7 bar | Current | 1.50 @ 12 VDC, 2.33 @ 12 VDC, 0.75 @ 24 VDC, 1.17 @ 24 VDC A |
| Leak Rate | 780 @ 3000 PSI (210 BAR) cm3/min | Hysteresis | 7% |
| Cavity Size | 4C | Flow Rate Accuracy | +/- 50% of Input Signal |
| Variation of Opening Point | 17% Nominal Amperage, 21% Nominal Amperage | Maximum Regulated Flow Rate | 7, 8 Gal/min |
| Seal Material | Nitrile | Flow Rate | 16 GAL/MIN, 60 L/MIN |
| Actuation Type | Electrical, Manual | Configuration | Normally Closed, Pressure Compensated |
