| UOM | EA | Maximum Operating Pressure | 3000 psi |
| Seal Material | Nitrile | Connection Size | n/a |
| Connection Type | n/a | Body Material | n/a |
| Division | Hydraulic Cartridge Systems Division | Division | Hydraulic Systems Division |
| Flow Direction | Bi-directional | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Minimum Operating Temperature | -30 °F | Weight | 0.26 lb |
| Flow Rate | 30 L/min | Cavity Size | C10-2 |
| Coil Type | 5/8" Super Coil High Watt (CAP) | Power Consumption | 28 W |
| Installation Torque | 30 Nm | Coil Nut Tightening Torque | 3 lb-ft |
| Maximum Inlet Pressure Rating | 210 bar | Maximum Operating Temperature | +121 °C |
| Function | Proportional Flow Control/Regulator | Frequency | 100-400 Hz |
| Actuation Type | Electrical, Manual | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Operation Type | Solenoid operated, Manually operated | Valve Material | All parts steel. All operating parts hardened steel |
| Operating Temperature | -34 to +121 °C | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Wire Mesh Screen Included | No | Variation of Opening Point | N/A |
| Minimum Pressure Differential | N/A psi | Override Functionality | Infinite Control |
| Hysteresis | < 10% | Configuration | Normally Open, Partially Pressure Compensated |
| Current | Max: 2.33 @ 12 VDC, 1.17 @ 24 VDC A | Leak Rate | 757 @ 3000 PSI (210 BAR) cm3/min |
| Maximum Flow Rate | 30.0 L/min | Flow Rate Accuracy | +/- 5% |
| Variation of Closing Point | 65% of Input Signal | Seal Material | Nitrile |
| Actuation Type | Electrical, Manual | Configuration | Normally Open, Partially Pressure Compensated |
| Flow Rate | 9.5 GAL/MIN, 36 L/MIN | | |
