| Maximum Operating Pressure | 3000 psi | Connection Size | n/a |
| Connection Type | n/a | Seal Material | Fluorocarbon |
| Body Material | n/a | Division | Hydraulic Cartridge Systems Division |
| Division | Hydraulic Systems Division | Flow Direction | Bi-directional |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Minimum Operating Temperature | -15 °F |
| Weight | 0.12 kg | Cavity Size | C10-2 |
| Installation Torque | 22 lb-ft | Coil Nut Tightening Torque | 3 lb-ft |
| Maximum Inlet Pressure Rating | 210 bar | Maximum Operating Temperature | +204 °C |
| Function | Proportional Flow Control/Regulator | Frequency | 100-400 Hz |
| Actuation Type | Electrical, Manual | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Operation Type | Solenoid operated, Manually operated | Valve Material | All parts steel. All operating parts hardened steel |
| Operating Temperature | -15 to +400 °F | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Wire Mesh Screen Included | No | Variation of Closing Point | N/A |
| Minimum Pressure Differential | N/A psi | Override Functionality | Infinite Control |
| Coil Type | 5/8" Super Coil | Hysteresis | < 10% |
| Configuration | Normally Closed, Partially Pressure Compensated | Current | Max: 1.50 @ 12 VDC, 2.33 @ 12 VDC, 0.75 @ 24 VDC, 1.17 @ 24 VDC A |
| Flow Rate | 8, 9.5 Gal/min | Leak Rate | 378 @ 3000 PSI (210 BAR) cm3/min |
| Maximum Flow Rate | 8, 9.5 Gal/min | Power Consumption | 18, 28 W |
| Flow Rate Accuracy | +/- 5% | Variation of Opening Point | 17% of Input Signal, 21% of Input Signal |
| Seal Material | Fluorocarbon | Actuation Type | Electrical, Manual |
| Configuration | Normally Closed, Partially Pressure Compensated | Flow Rate | 8, 9.5 GAL/MIN, 30, 36 L/MIN |
