| Actuation Type | Electrical | Connection Size | n/a |
| Connection Type | n/a | Seal Material | Fluorocarbon |
| Body Material | n/a | Division | Hydraulic Valve Systems Division |
| Division | Hydraulic Systems Division | Flow Direction | Bi-directional |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Minimum Operating Temperature | -15 |
| Weight | 0.26 | Maximum Operating Pressure | 3000 |
| Override Functionality | n/a | Cavity Size | C10-2 |
| Operation Type | Solenoid Operated | Installation Torque | 22 |
| Coil Nut Tightening Torque | 3 | Maximum Inlet Pressure Rating | 3000 |
| Function | Proportional Flow Control/Regulator | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Valve Material | All parts steel. All operating parts hardened steel | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Wire Mesh Screen Included | No | Variation of Closing Point | N/A |
| Operating Temperature | -15 to +400 | Frequency | 100-400 |
| Maximum Operating Temperature | +400 | Coil Type | 5/8" Super Coil |
| Hysteresis | < 10% | Configuration | Normally Closed, Partially Pressure Compensated |
| Minimum Pressure Differential | N/A | Current | Max: 1.50 @ 12 VDC, 2.33 @ 12 VDC, 0.75 @ 24 VDC, 1.17 @ 24 VDC |
| Flow Rate | 8, 9.5 | Leak Rate | 378 @ 3000 PSI (210 BAR) |
| Maximum Flow Rate | 8, 9.5 | Power Consumption | 18, 28 |
| Flow Rate Accuracy | +/- 5% | Variation of Opening Point | 17% of Input Signal, 21% of Input Signal |
| Seal Material | Fluorocarbon | Actuation Type | Electrical |
| Configuration | Normally Closed, Partially Pressure Compensated | Flow Rate | 8, 9.5 GAL/MIN, 30, 36 L/MIN |
