*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker H90AT2AA17580AS - gpd H Model

Parker’s Aluminum Pump H Series fixed displacement gear pump offers high performance and high power density due to its aluminum construction.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. H90AT2AA17580AS

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Flow Rate	n/a	Body Material	Aluminum
Division	Pump & Motor Division	Media	n/a
Pump Type	Fixed	Maximum Flow Rate	n/a
Direction of Rotation	Clockwise	Maximum Operating Pressure	172 bar
Mounting Type	2-Bolt SAE AA	For Fluid Type	Water Emulsions (w/DU Bushings)
Operating Temperature	-42 to 85 °C	Filter Efficiency Rating	Maintain SAE Class 4
Rated Speed	500 to 4000 RPM	Product Type	Aluminum Pump w/bearing sleeve, fixed displacement
Maximum Continuous Pressure	172.0 bar	Weight	5 to 7 lb
Displacement	36.5 cm3/rev	Maximum Displacement	2.227 inch3/rev
Maximum Kinematic Viscosity	1000 SUS (Operating)	Overall Length	189.99 mm
Rotation	ClockWise	Shaft Seal Material	NBR
Pressure Relief Setting (psig)	1750 psi	Options	includes Anti-Ripple Wearplate
Porting	UNF-2B SAE Striaght Thread: 1-5/16-12 Inlet - Rear, 3/4-16 Primary - Rear, 7/8-14 Secondary - Side	Pressure Relief Valve	R/V returns to Pump Inlet Internal - Secondary Port External
Shaft Type	11-Tooth Spline	Flow Rate (gpm)	8 GPM
Pump Displacement (cu in/rev)	H90: 2.227 (36.50 cc/rev)
