| UOM | EA | Frequency | 100-400 Hz |
| Maximum Regulating Pressure | 41-51 bar | Maximum Tank Pressure | N/A psi |
| Configuration | Side Cylinder Port | Hysteresis | 3.5% |
| Function | Proportional Pressure Reducing | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Valve Material | All parts steel. All operating parts hardened steel | Flow Direction | Inlet port 3, Reducing port 2, Tank port 1 |
| Maximum Pressure Setting | N/A psi | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Maximum Inlet Pressure Rating | 3000 psi |
| Override Functionality | N/A | Coil Type | 1/2" Super Coil High Watt (CCP) |
| Division | Hydraulic Cartridge Systems Division | Cavity Size | C08-3 |
| Maximum Operating Temperature | +121 °C | Current | 1.4 at 12VDC (High watt), 0.7 at 24VDC (High watt) A |
| Installation Torque | 27 Nm | Minimum Operating Temperature | -30 °F |
| Division | Hydraulic Systems Division | Operating Temperature | -30 to +250 °F |
| Maximum Flow Rate | 19 L/min | Maximum Drain Flow Rate | 100 De-Energized, 750 In Regulating Zone @ 300 PSI (21 BAR) cm3/min |
| Leak Rate | N/A cm3/min | Body Material | N/A |
| Operation Type | Solenoid operated | Mounting Type | Screw in cartridge valve |
| Actuation Type | Electrical | Weight | 0.17 lb |
| Maximum Operating Pressure | 3000 psi | Coil Nut Tightening Torque | 3 lb-ft |
| Power Consumption | 19 W | Response Time | 10 ms |
| Seal Material | Nitrile | Wire Mesh Screen Included | Yes |
| Flow Rate | 19 L/min | Seal Material | Nitrile |
| Override Functionality | N/A | Maximum Inlet Pressure Rating | 3000 PSI, 210 BAR |
| Maximum Flow Rate | 5 GAL/MIN, 19 L/MIN | Wire Mesh Screen Included | Yes |
| Configuration | Side Cylinder Port | Maximum Regulating Pressure | 600-740 PSI, 41-51 BAR |
