Parker FF-502-12FP - Flat Face, HTMA, Hydraulic Quick Couplings - FF and FC Series

Parker's non-spill, flat face hydraulic couplers and nipples are ideal for use across a variety of hydraulic applications where fluid lines require fast and easy connection and disconnection with minimal spillage and limited air inclusion

Availability:	Quote Required
Partner Available:	15 In Stock

Brand Parker

Part No. FF-502-12FP

$155.46

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Application	Hydraulic, non-spill
Flow Rate	12 Gal/min	Seal Material	Polyurethane and Nitrile
Minimum Operating Temperature	-40 °F	Division	Quick Coupling Division
Product Type	Push to Connect	Valve Type	Non-spill
Body Material	Steel	Maximum Operating Temperature	250 °F
Hex Size	36 mm	Plating Type	Zinc nickel plating
Coupling Half	Male Nipple	Body Size (inch)	1/2
Connection Type	Female NPTF	Maximum Operating Pressure	3000
Interchange Type	na	Connection Thread Size (inch)	3/4 - 14
