Parker FF-252-6MO - Flat Face, HTMA, Hydraulic Quick Couplings - FF and FC Series

Name: Parker FF-252-6MO - Flat Face, HTMA, Hydraulic Quick Couplings - FF and FC Series
SKU: FF-252-6MO
Price: 104.19 USD
Availability: InStock

Parker's non-spill, flat face hydraulic couplers and nipples are ideal for use across a variety of hydraulic applications where fluid lines require fast and easy connection and disconnection with minimal spillage and limited air inclusion

AFP Availability:

1 Limited Stock

West Knoxville, TN

Partner Available:

Quote Required

Quantities sourced from Partner Network may incur an upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

Brand Parker

Part No. FF-252-6MO

$104.19/each

Qty:

Products specifications

Attribute name	Attribute value
UOM	EA	Seal Material	Nitrile
Division	Quick Coupling Division	Maximum Operating Temperature	250 °F
Valve Type	Non-spill	Hex Size	1.00 inch
Body Material	Steel	Flow Rate	3 Gal/min
Application	Hydraulic, Non-spill	Minimum Operating Temperature	-40 °F
Plating Type	Zinc with clear trivalent chromate	Product Type	Push to connect
Connection Thread Size (inch)	9/16-18	Body Size (inch)	1/4
Connection Type	Male UNF	Maximum Operating Pressure	5000
Interchange Type	na	Coupling Half	Male Nipple
