Parker FCNV12081 - Needle Valve, FCNV Series - 22,500 PSI

Parker Autoclave’s FCNV Series needle valve is specifically designed to interface with the FCC Flared Cone Connection to 22,500 psi (1,550 bar). The needle valves are available to connect with 1/4" to 1” O.D. Parker Autoclave tube sizes.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. FCNV12081

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Body Type	2 way straight	Connection Size	FLC750
Pressure Rating	20000 PSI (Stainless Steel as standard), 22500 PSI (Super Duplex option)	Options	For extreme temperature and other options consult factory
Division	Instrumentation Products Division	Orifice Size	0.438
Flow Rate	2.5	Stem Type	Non Rotating regulating stem (tapered tip for regulating and shutoff)
Tube Outside Diameter	3/4"	Stem Type	Non Rotating regulating stem (tapered tip for regulating and shutoff)
Body Pattern	2 way straight	Tube O.D. (inch)	3/4"

Product resources

02-0142SE

Autoclave Engineers Technicial/Special Materials Data Catalog (PDF)

Literature and Reference Materials

Autoclave Engineers: Flared Cone Connection (FCC) Datasheet (PDF)

Literature and Reference Materials, Training

Autoclave Engineers: Flared Cone Connection New Faster Tube Connection Technology (PDF)

02-9319BE

Autoclave Engineers: FCC Series-Flare Coned Connection Product Catalog, Valves, Fittings, Adapters and Tubing Specifically for use with FCC Connection (PDF)
