| UOM | EA | Actuation Type | Electrical |
| Body Material | n/a | Maximum Operating Pressure | 5000 psi |
| Division | Hydraulic Cartridge Systems Division | Division | Hydraulic Systems Division |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Minimum Operating Temperature | -37 °C |
| Cavity Size | C10-3L | Override Functionality | n/a |
| Wire Mesh Screen Included | n/a | Maximum Inlet Pressure Rating | 350 bar |
| Seal Material | D-Ring (Standard) | Operation Type | Solenoid Operated |
| Maximum Flow Rate | 10 Gal/min | Configuration | Pressure Reducing/Relieving |
| Hysteresis | 4% | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Valve Material | All parts steel. All operating parts hardened steel | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Mounting Type | Screw in cartridge valve | Operating Temperature | -35 to +200 °F |
| Maximum Operating Temperature | +93 °C | Weight | 1.3 lb |
| Coil Type | 1/2" Super Coil Low Watt (CCS) | Installation Torque | 50-56 Nm |
| Maximum Tank Pressure | N/A psi | Function | Proportional Pressure Reducing |
| Frequency | 200-600 Hz | Response Time | N/A ms |
| Maximum Drain Flow Rate | N/A cm3/min | Maximum Pressure Setting | N/A psi |
| Coil Nut Tightening Torque | 7-9.5 Nm | Current | 0.9 at 12VDC, 0.45 at 24VDC A |
| Flow Rate | 37.5 L/min | Leak Rate | 492 @ 300 PSI (21 BAR), 946 @ 3000 PSI (210 BAR) cm3/min |
| Flow Direction | Inlet port 1, Reducing port 2, Tank port 3 | Power Consumption | 9 @ Max Reduced Pressure W |
| Maximum Regulating Pressure | 21 bar | Override Functionality | N/A |
| Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR | Seal Material | D-Ring (Standard) |
| Configuration | Pressure Reducing/Relieving | Wire Mesh Screen Included | N/A |
| Maximum Flow Rate | 10 GAL/MIN, 37.5 L/MIN | Maximum Regulating Pressure | 300 PSI, 21 BAR |
