Parker BST-N2 - High Flow, Unvalved, Hydraulic Quick Couplings - ST Series

Name: Parker BST-N2 - High Flow, Unvalved, Hydraulic Quick Couplings - ST Series
SKU: BST-N2
Price: 8.33 USD
Availability: InStock

Parker's high flow quick couplers and nipples are unvalved for use where fluid lines require fast and easy connection and disconnection while providing maximum flow and low pressure drop.

AFP Availability:

64 In Stock

Norfolk, VA	22
Fayetteville, NC	12
Richmond, VA	6
Richmond, VA	6 (Pickup only)
Jacksonville, FL	4
Knoxville, TN	4
Knoxville, TN	3
Mooresville, NC	3
Ashland, VA	2 (Pickup only)
Johnson City, TN	2 (Pickup only)

Partner Available:

590 In Stock

Brand Parker

Part No. BST-N2

$8.33/each

Qty:

Products specifications

Attribute name	Attribute value
UOM	EA	Minimum Operating Temperature	-40 °F
Product Type	Push to Connect	Maximum Operating Temperature	250 °F
Flow Rate	6 Gal/min	Hex Size	0.75 inch
Valve Type	Unvalved	Dimensional Weight	0.013329336530775381 lb
Application	High Flow	Plating Type	n/a
Seal Material	n/a	Division	Quick Coupling Division
Body Material	Brass	Maximum Operating Pressure	5200
Connection Type	Female NPTF	Body Material	BRASS
Connection Thread Size (inch)	1/4 - 18	Body Size (inch)	1/4
Coupling Half	Male Nipple

Product resources

Literature and Reference Materials

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories (PDF)
