| Maximum Operating Temperature | 400 | Seal Material | Fluorocarbon |
| Body Material | n/a | Maximum Operating Pressure | 4000 |
| Division | Hydraulic Valve Systems Division | Division | Hydraulic Systems Division |
| Configuration | Normally Open (NO) | Flow Direction | Nose to Side (1-2) |
| For Fluid Type | Synthetic Hydraulic Fluids | Valve Material | Steel (all parts) |
| Operating Temperature | -15 to 400 | Filter Efficiency Rating | SAE Class 4 |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Minimum Operating Temperature | -15 |
| Weight | 0.98 | Adjustment Mechanism | Tamper Resistant |
| Cavity Size | C10-2 | Installation Torque | 37 |
| Coil Type | 5/8" Super Coil High Watt (CAP) | Coil Nut Tightening Torque | Finger Tight |
| Maximum Flow Rate | 16 | Flow Rate | 16 |
| Function | Unloading Relief Valve | Leak Rate | 5 cm3/min for Every 100 Psi of Setting |
| Actuation Type | Solenoid | Reseat Pressure | 90% of Cracking Pressure |
| Maximum Tank Pressure | 1000 | Pressure Control Range | 100 to 4000 |
| Standard Setting Pressure | 2000 | Maximum Inlet Pressure Rating | 4000 |
| Minimum Pressure Differential | 100 | Seal Material | Fluorocarbon |
| Adjustment Mechanism | Tamper Resistant | Standard Setting Pressure | 2000 PSI, 140 BAR |
