Parker 933352 - Replacement Elements - Medium Pressure Filter IL8 Series

The Parker IL8 Coreless Medium Pressure Filter Series are engineered with the latest in Microglass technology. IL8 Filters utilize a reusable core which remains in service through the life of the assembly.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 933352

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Product Type	Hydraulic Filter Element	Product Style	Hydraulic Filter
Division	Engine Mobile Hydraulic and Fuel Filtration Division	For Fluid Type	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids
Filter Element Type	Coreless	Length	double
Filter Housing Series	IL82	Filter Element	40W stainless steel mesh
Seal Material	Fluorocarbon	Collapse Pressure (bar)	10.3 bar
Efficiency βx(C) ≥ 200	40 (nominal) µ	Media Type	Stainless steel mesh
Seals	FKM: Fluorocarbon	UOM	EA
Pkg Qty	1	Collapse Pressure (psi)	150 psi
Efficiency βx(C) ≥ 200	40 (nominal) µ	Glue Side Seam Adhesive	Weld
Media	40 Micron Nominal	Inner Support Cylinder Material	Steel tin plated
Parker Division	Hydraulic Filter	Glue Endcaps Adhesive	Epoxy
Series	ParFit	Top Endcap Material	Glass reinforced nylon
Seals	FKM: Fluorocarbon	Parker Group	Filtration
A Dimension	6.098 in (154.9 mm)	Bottom Endcap Material	Glass reinforced nylon
E Dimension	1.85 in (47 mm)	D Dimension	6.098 in (154.9 mm)
Collapse Pressure (bar)	10.3 bar	Media Composition Detail	Single layer stainless steel mesh
B Dimension	0.606 in (15.4 mm)	Media Type	Stainless steel mesh
Collapse Pressure (psi)	150 psi
