Parker 83FR-12-BLK-RL - Polyurethane Hose - 83FR

Flame Resistant 83FR Polyurethane Hose is Parker’s most durable, multipurpose flame retardant hose for air and water. It is MSHA accepted and often used in robotic welding applications.

AFP Availability:	Quote Required
Partner Available:	2119 In Stock

Brand Parker

Part No. 83FR-12-BLK-RL

$7.26/foot

Products specifications

Attribute name	Attribute value
UOM	FT	Cover Material	Polyurethane
Specifications Met	SAE J517 (non-conductivity)	Minimum Bend Radius	89 mm
Hose Reinforcement Material	Fiber	Weight	0.19 kg/m
Design Factor	4:1	Hose Inner Tube Material	Specially Formulated Polyurethane
Application	Robotics	Minimum Operating Temperature	-29 °C
Division	Parflex Division	Maximum Operating Temperature	93 °C
Compatible Fitting	82 Series (temperature range reduced to 145°F/63°C with 82 Series)	Media	Air
Maximum Operating Pressure	2.1 MPa	Outside Diameter	1.040 inch
Inside Diameter	3/4 inch	Vacuum Pressure Rating	n/a
Hose I.D. (inch)	3/4	Color	Black

Product resources

Literature and Reference Materials

Compliance, Certifications & Safety

Distributor Support

Welding Hose Safety Bulletin (PDF)
