Parker 787-10-RL - 787 Series

High Constant Pressure 5000 PSI Hydraulic Hose

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 787-10-RL

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Inner Diameter	0.625 Inch	Material	Rubber
Mating Fitting Series	77	Working Pressure	5,000 psi (35 MPa)
Parker Group	Fluid Connector	Inch/Metric	Inch
Parker Division	Hose Products	Inner Diameter	0.625 Inch
Inner Diameter Inch/mm	Inch	Material	Rubber
Application	Hydraulic	Working Pressure Range	> 5000 PSI (345 bar)
Hose Category	Hydraulic Industry Standard	Operating Temperature	-40°F to +212°F (-40°C to +100°C)
Trade Name	GlobalCore	Mating End Fitting Series	77
Specification	ISO 18752	ISO 18752 Performance	BC
Minimum Bend Radius	4 Inch	Hose Pressure Range	High
Series	787	Distinct Properties	Constant Pressure 5000 PSI
Working Pressure	5,000 psi (35 MPa)
