Parker 73312BN52NJ0N0H111P3 - Parker 3-Way Normally Closed, 3/4" NPT General Purpose Solenoid Valves

Parker 3-Way Normally Closed, 3/4" NPT Solenoid Valves provide operating pressures of 180 psi and flow factors of 7.3 CV's. They offer a brass body, multiple mounting positions and coil options for all general purpose flow control applications.

AFP Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 73312BN52NJ0N0H111P3

$968.52/each

Products specifications

Attribute name	Attribute value
UOM	EA	Function	Normally Closed (NC)
Flow Coefficient 2	n/a	Additional Options	Exhaust Return Pipe
Product Series	7000 Series	Minimum Fluid Temperature	0 °F
Valve Type	3-Way	Orifice 2 Size	n/a
Number of Ports	3	Coil Type	1/2" NPT Conduit, 18" Leads, Class F, NEMA 7, 9
Exhaust Orifice Size	n/a	Division	Fluid Control Division
Body Material	Brass	Media	General Purpose for Air
Minimum Pressure Differential	10 psi	Input Voltage	110/50-120/60
Main Flow Coefficient	7.3 Cv	Port Size	3/4 inch
Coil Specifications Met	NEMA 7	Exhaust Flow Coefficient	n/a
Port Type	NPT	Maximum Pressure Differential	180 psi (AC)
Power Consumption	10 W (AC)	Seal Material	NBR
Main Orifice Size	3/4 inch	Actuation Type	Manual
Maximum Fluid Temperature	185 °F	Voltage (V)	110/50-120/60
Power (Watts)	10 Watt (AC)	Coil Type	1/2" NPT Conduit, 18" Leads, Class F, NEMA 7, 9
Maximum Pressure Differential (psi)	180 psi (AC)

Product resources

Literature and Reference Materials

73312/73322/73382 Installation, Operation & Maintenance Instructions (PDF)
