Parker 68NTA-4-MI10 - ISO Port Adapters

Parker's ISO Port Adapters are ideal in systems with high pressure and cycling providing reliable, long-term sealing. ISO port adapters meet dimensional requirements of ISO 6149-3 and SAE 2244-3.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 68NTA-4-MI10

$17.30

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Tube Material	Copper, Brass, J844 Type A & B Nylon Tubing
Maximum Operating Temperature	200 °F	Division	Fluid System Connectors Division
Minimum Operating Pressure	-40 psi	Minimum Operating Temperature	-40 °F
O-Ring Material	Fluorocarbon	Maximum Operating Pressure	10 bar
Specifications Met	ISO 6149-3, SAE 2244-3	Body Material	Brass
Connection 1 Tube O.D. (inch)	1/4	Connection 1 Style	Compression
Connection 2 Thread Size (inch)	M10x1.0	Shape	Connector
Style	Compression to Metric

Product resources

Compliance, Certifications & Safety

Literature and Reference Materials

Compliance, Certifications & Safety, Literature and Reference Materials

FSC REACH Product Declaration (PDF)
