Parker 6693 17 21 - Transair® Wall Brackets for Aluminum Pipe

Transair® Wall Brackets are designed for quick connection of machinery or tools to compressed air piping systems or inert gas supply lines.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 6693 17 21

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Brand	Transair	Division	Low Pressure Connectors Europe Division
Division	Fluid System Connectors Division	Assembly Time	0.15 Hours
Shape	Straight	Minimum Operating Temperature	-4 °F
Industry	General Industrial	Assembly	n/a
Seal Material	NBR	Application	Industrial Gas
Technology	Pneumatics	Specifications Met	EN 573.3
Maximum Operating Temperature	185 °F	For Fluid Type	Air
Connection 1 Type	Pipe	Connection 2 Type	Female BSPP
Body Material	Treated Brass	Quantity per Box	2
Connection 1 Size	1/2 inch	Configuration	Pipe to Port
Product Type	Wall Brackets	Connection 2 Size	G 1/2 inch
Maximum Operating Pressure	232 psi 232 PSI (-4°F to +113°F)/16 bar (-20°C to 45°C) up to 100 mm 188 PSI (-4° to +140°F)/13 bar (-20°C to 60°C) up to 168 mm 101 PSI (-4° to +185°F)/7 bar ( -20°C to 85°C) up to 168 mm For Canada, Please refer to https://www.parker.com/c	Connection 3 Size	G 1/4 inch
Connection 3 Type	Female BSPP	Weight	2,535 lb
Pipe O.D. (mm)	16.5	Pipe O.D. (inch)	1/2
Connection Thread Size (inch)	n/a	Shape	2 Port 45° Wall Bracket with Ball Valve
