Parker 6679 25 22 - Transair® Wall Brackets for Aluminum Pipe

Transair® Wall Brackets are designed for quick connection of machinery or tools to compressed air piping systems or inert gas supply lines.

Availability:	Quote Required
Partner Available:	6 In Stock

Brand Parker

Part No. 6679 25 22

$217.21

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Brand	Parker
Assembly Time	0.15 Hours	Shape	Straight
Maximum Operating Temperature	85 °C	Minimum Operating Temperature	-4 °F
Industry	General Industrial	Technology	Fluid & Gas Handling
Division	Fluid System Connectors Division	Assembly	n/a
Connection 2 Type	Female NPT	Division	Low Pressure Connectors Europe Division
Seal Material	NBR	Application	Inert Gases
Specifications Met	EN 755.2	For Fluid Type	Air
Connection 1 Type	Pipe	Quantity per Box	1
Body Material	Technical Polymer	Configuration	Pipe to Port
Connection 1 Size	25 mm	Product Type	Wall Brackets
Connection 2 Size	NPT 1/2 inch	Maximum Operating Pressure	232 psi 232 PSI (-4°F to +113°F)/16 bar (-20°C to 45°C) up to 100 mm 188 PSI (-4° to +140°F)/13 bar (-20°C to 60°C) up to 168 mm 101 PSI (-4° to +185°F)/7 bar ( -20°C to 85°C) up to 168 mm For Canada, Please refer to https://www.parker.com/c
Connection 3 Size	NPT 1/4 inch	Connection 3 Type	Female NPT
Weight	1,528 kg	Pipe O.D. (mm)	25
Pipe O.D. (inch)	1	Connection Thread Size (inch)	n/a
Shape	1 Port 45° Wall Bracket with Ball Valve
