Parker 4981 10 21TR - Transair® Valves for Aluminum Pipe

Transair® Valves are designed for quick and easy integration into a Transair compressed air piping system. Placing valves at strategic points allows for easy system isolation.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 4981 10 21TR

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Orifice Size	25 mm	Division	Fluid System Connectors Division
Weight	0.304 lb	Quantity per Box	1
Seal Material	NBR	Proof Pressure	n/a
Seat Material	PTFE	Specifications Met	EN 573.3
For Fluid Type	Industrial Gases	Function	2-Way
Response Time	n/a	Burst Pressure	n/a
Actuation Type	Manual	Maximum Flow Rate	n/a
Division	Fluid System Connectors Division	Connection 1 Size	R1/2 inch
Product Style	Ball Valve	Connection 2 Size	R1/2 inch
Body Material	Treated Brass	Assembly Time	0.1 Hours
Maximum Operating Pressure	16 bar 232 PSI (-4°F to +113°F)/16 bar (-20°C to 45°C) up to 100 mm 188 PSI (-4° to +140°F)/13 bar (-20°C to 60°C) up to 168 mm 101 PSI (-4° to +185°F)/7 bar ( -20°C to 85°C) up to 168 mm For Canada, Please refer to https://www.parker.com/ca	Power Consumption	n/a
Operation Type	Manual	Connection 2 Type	Female BSPT
Mounting Type	In-line/Pipe	Brand	Parker
Vacuum Pressure Rating	0.03 inch-Hg	Connection 1 Type	Male BSPT
Technology	Fluid & Gas Handling	Industry	General Industrial
Maximum Operating Temperature	85 °C	Model Number	n/a
Application	In Plant Pneumatic	Flow Direction	Bidirectional
Options	Lockable	Configuration	Port to Port
Pressure Differential	n/a	Flow Coefficient	n/a
Product Type	Flow Control Valve	Cavity Size	n/a
Number of Ports	n/a	Minimum Operating Temperature	-4 °F
Pressure Rating	n/a	Connection Thread Size (inch)	1/2
Vented	No	Silicone Free	Yes
Pipe O.D. (inch)	N/A	Pipe O.D. (mm)	N/A
Style	Ball Valve
