| Division | TAIYO Division | Seal Material | HNBR |
| Body Material | aluminum alloy | Fluid Type | Petroleum-based fluid(When using another fluid,give us such instructions.) |
| Screw Tolerance | JIS 6g/6H | Type | Double Acting Single Rod, Switch set |
| Rod End Thread Type | Female thread and male thread | Stroke Length Tolerance (mm) | 0-+1.0 |
| Cushioning Type | None | Speed Range | 8-100mm/s |
| Mounting Style | SD | Bore Diameter (mm) | 20, 32, 40, 50, 63 |
| Proof Pressure (MPa) | 5 | Temperature Range (C) | -10-+70（AX type）, -10-+60 (WR,WS type, No freezing, ambient/fluid temperature) |
| Nominal Pressure (MPa) | 3.5 | Maximum Working Pressure (MPa) | 4 |
| Minimum Operating Pressure (MPa) | 0.15(φ20-32), 0.1(φ40-63) | | |
