Parker 320R-RAC-01 - Marine Fuel Filter Water Separator – Racor Spin-on Series

Racor Marine Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. UL-approved versions available.

AFP Availability:	Quote Required
Partner Available:	4 In Stock

Brand Parker

Part No. 320R-RAC-01

$164.01/each

Products specifications

Attribute name	Attribute value
UOM	EA	Operating Temperature	-40 to 121 °C
Maximum Fluid Temperature	190.0 °F	Depth	4 inch
Height	23.9 cm	Number of Ports	2 Inlet / 1 Outlet
Mounting Type	Bracket Included	Width	10.2 cm
Clean Pressure Drop	0.6 psi	Filter Element Type	10 Micron Aquabloc Spin-on
Division	Engine Mobile Original Equipment Division	Compatible Element	S3227 = 10 micron<br/>S3228SUL = 2 micron
Product Series	Gasoline Spin-on	Brand	Racor
Weight	2.0 lb / 0.5 Kg	Maximum Operating Pressure	7 psi
Head Material	Power Coated Aluminium Alloy	Micron Rating	98% @ 10 Micron
Bowl Material	Clear Engineering Plastic	Port Size	1/4”-18 NPTF
Filtered Medium	Gasoline	UL Certification	No
Integral Primer Pump	No	Flow Rate	60 gph / 227 lph
