Parker 3-Way Normally Closed, 3/8" NPT General Purpose Solenoid Valves
*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.
AFP Industries stocks this Parker series for quote or purchase, with interchange support and southeast warehouse availability.
Parker's 3-Way Normally Closed, Direct Acting 3/8" NPT Solenoid Valves are used in a wide variety of applications ideally suited for low to medium pressure applications that do not require a minimum operating pressure differential. Ideally suited for general purpose air, liquids and gases, these valves are available in brass and stainless steel construction. Coil options are available in 1/2" NPT Conduit and DIN Form A in Class F and H or NEMA 4X, 7 or 9 specification.
Markets:
• Commercial Equipment
• Food & Beverage
• Industrial Automation
• Oil & Gas
• Process Control
• Transportation
Features/ Benefits:
• High Quality Standards of Skinner® and Gold Ring™ Brand
• Modular Design
• Long Life
• Tight Shutoff
Applications:
• Single acting spring return cylinder control
• Selection or diversion of process media
• HVAC damper control
• Instrumentation Equipment
• Pneumatic positioning
• Automatic dispensing equipment
• Gas sampling
• Small compressors
• Water treatment
• Air dryers
• Analyzers and Diagnostic Equipment
• Medical and Dental Equipment
• Portable Welding Equipment
• Spraying Equipment
• Lubrication Equipment
• Textile and Dry Cleaning Equipment
• Irrigation Equipment
| Action | Part No. | Availability | Partner Available | Price | UOM | Exhaust Orifice Size | Valve Type | Flow Coefficient 2 | Minimum Fluid Temperature | Additional Options | Function | Product Series | Orifice 2 Size | Coil Type | Number of Ports | Media | Coil Specifications Met | Division | Port Size | Minimum Pressure Differential | Body Material | Main Flow Coefficient | Input Voltage | Maximum Pressure Differential | Exhaust Flow Coefficient | Actuation Type | Power Consumption | Seal Material | Maximum Fluid Temperature | Port Type | Main Orifice Size | Coil Type | Voltage (V) | Power (Watts) | Maximum Pressure Differential (psi) | Mechanical Option |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 73312BN3RNJ0N0C111P3 | Quote Required | $634.48/each | EA | n/a | 3-Way | n/a | 0 °F | Exhaust Return Pipe | Normally Closed (NC) | 7000 Series | n/a | 1/2" NPT Conduit, 18" Leads, Class F, NEMA 4X | 3 | General Purpose for Air | NEMA 4X | Fluid Control Division | 3/8 inch | 10 psi | Brass | 2.1 Cv | 110/50-120/60 | 180 psi (AC) | n/a | Manual | 10 W (AC) | NBR | 185 °F | NPT | 3/8 inch | 1/2" NPT Conduit, 18" Leads, Class F, NEMA 4X | 110/50-120/60 | 10 Watt (AC) | 180 psi (AC) | Exhaust Return Pipe | ||
| 73312BN3RNJ1N0C111P3 | Quote Required | $632.63/each | EA | n/a | 3-Way | n/a | 0 °F | Exhaust Adapter Nut | Normally Closed (NC) | 7000 Series | n/a | 1/2" NPT Conduit, 18" Leads, Class F, NEMA 4X | 3 | Liquids and Gases | NEMA 4X | Fluid Control Division | 3/8 inch | 10 psi | Brass | 2.1 Cv | 110/50-120/60 | 180 psi (AC) | n/a | Mechanical | 10 W (AC) | NBR | 185 °F | NPT | 3/8 inch | 1/2" NPT Conduit, 18" Leads, Class F, NEMA 4X | 110/50-120/60 | 10 Watt (AC) | 180 psi (AC) | Exhaust Adapter Nut | ||
| 73312BN3RNJ1N0C222P3 | 1 Limited Stock | Quote Required | $664.15/each | EA | n/a | 3-Way | n/a | 0 °F | Exhaust Adapter Nut | Normally Closed (NC) | 7000 Series | n/a | 1/2" NPT Conduit, 18" Leads, Class H, NEMA 4X | 3 | General Purpose for Air | NEMA 4X | Fluid Control Division | 3/8 inch | 10 psi | Brass | 2.1 Cv | 110/50-120/60 | 180 psi (AC) | n/a | Manual | 10 W (AC) | NBR | 185 °F | NPT | 3/8 inch | 1/2" NPT Conduit, 18" Leads, Class H, NEMA 4X | 110/50-120/60 | 10 Watt (AC) | 180 psi (AC) | Exhaust Adapter Nut |
