Parker 27990-12-12 - Field Attachable Fittings for PTFE Hose - 90 Series

Name: Parker 27990-12-12 - Field Attachable Fittings for PTFE Hose - 90 Series
SKU: 27990-12-12
Price: 69.32 USD
Availability: InStock

Parker's 90 Series fittings are used with 919/919B PTFE hoses from Parflex division.

AFP Availability:

3 In Stock

Fayetteville, NC

Partner Available:

Quote Required

Quantities sourced from Partner Network may incur an upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

Brand Parker

Part No. 27990-12-12

$69.32/each

Qty:

Products specifications

Attribute name	Attribute value
UOM	EA	Division	Parflex Division
For Fluid Type	Gases	Connection 2 Size	1-1/16"-14 inch Thread
Fitting Length	3.03 inch (see drawing legend A)	Configuration	Hose to Port
Dimensional Weight	0.5886 lb	Hex Size	1-1/8 inch (see drawing legend H)
Connection 1 Size	5/8 inch Hose I.D.	Body Material	Steel
Coating	Chromium 6 Free-plated	Connection 2 Type	45° Flare SAE
Connection Length	2 inch Cut-off allowance (see drawing legend B)	Technology	Fluid & Gas Handling
Hex Size 1	1-1/4 inch (see drawing legend J)	Connection 1 Type	Hose
Product Type	Hose Fittings	Specifications Met	n/a
Shape	Elbow 90°	Division	Parflex Division
Application	Tools & Equipment	Maximum Operating Pressure	3000 psi (Dependent on hose)
Product Series	90	Brand	Parker
Industry	Healthcare & Life Sciences	Tube Outside Diameter	n/a
Hose I.D. (inch)	0.625"	Length (inch)	2.51"
Connection 2 Size	1-1/16"-14	Product Style	Female SAE 45 / Swivel - 45° Elbow
