Picture of Parker 245RMAM - Marine Fuel Filter Water Separator – Racor Spin-on Series

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker 245RMAM - Marine Fuel Filter Water Separator – Racor Spin-on Series

Racor Marine Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. UL-approved versions available.
Availability:
Quote Required
Partner Available:Quote Required
Brand Parker
Part No. 245RMAM
TBD
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
DivisionEngine Mobile Original Equipment DivisionBrandRacor
Maximum Operating Pressure30Filter Element Type10 Micron Aquabloc Spin-on
Operating Temperature-40 to 250Maximum Fluid Temperature190.0
Head MaterialPower Coated Aluminium AlloyMounting TypeBracket Included
Product SeriesMarine Spin-on FF/WSDepth4
Width4Number of Ports1 Inlet / 2 Outlet
Weight2.2 lb / 1.0 KgHeight26.7
Compatible ElementR25TUL = 10 micron<br/>R25P = 30 micron<br/>R25S = 2 micronClean Pressure Drop0.6
Micron Rating98% @ 10 MicronPort Size1/4”-18 NPTF
Bowl MaterialAluminum BowlFiltered MediumDiesel
UL CertificationYesIntegral Primer PumpYes
Flow Rate45 gph / 170 lph
