Parker 245IFHD-4-2 - Brass Inverted Flare Fittings

Parker's economical inverted flare fittings offer a metal-to-metal seal that is internal to the fitting for tighter tube bends. Meets functional requirements of SAE J512

AFP Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 245IFHD-4-2

$23.81/each

Products specifications

Attribute name	Attribute value
UOM	EA	Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Nut Material	Brass, Zinc Chromate Steel	Division	Fluid System Connectors Division
Maximum Operating Temperature	121 °C	Application	Pumps, Brake Lines
Minimum Operating Temperature	-53 °C	Body Material	Brass
Maximum Operating Pressure	1400 psi	Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared
Specifications Met	SAE J512	Shape	Branch Tee
Connection 2 Thread Size (inch)	1/8	Connection 2 Tube O.D. (inch)	na
Connection 1 Tube O.D. (inch)	1/4	Connection 2 Style	Male Pipe
Style	Flare to Pipe	Connection 1 Style	Inverted Flare
