Parker 23790-6-6 - Field Attachable Fittings for PTFE Hose - 90 Series

Parker's 90 Series fittings are used with 919/919B PTFE hoses from Parflex division.

AFP Availability:	Quote Required
Partner Available:	1 Limited Stock

Brand Parker

Part No. 23790-6-6

$37.10/each

Products specifications

Attribute name	Attribute value
UOM	EA	Technology	Fluid & Gas Handling
Dimensional Weight	0.0264 lb	For Fluid Type	Oil
Connection 2 Size	9/16"-18 inch Thread	Division	Parflex Division
Configuration	Hose to Port	Fitting Length	50 mm
Division	Parflex Division	Body Material	Steel
Connection 2 Type	Female	Coating	Chromium 6 Free-plated
Connection Length	44 mm	Connection 1 Size	5/16 inch Hose I.D.
Hex Size	11/16 inch (see drawing legend H)	Connection 1 Type	Hose
Specifications Met	n/a	Hex Size 1	11/16 inch (see drawing legend J)
Tube Outside Diameter	n/a	Product Type	Hose Fittings
Application	Medical	Shape	Elbow 45° Short Drop
Product Series	90	Brand	Parker
Industry	Food & Beverage	Maximum Operating Pressure	207 bar
Hose I.D. (inch)	0.313"	Length (inch)	1.96"
Connection 2 Size	9/16"-18	Product Style	Female JIC 37° - Swivel - 45° Elbow - Short Drop
