Picture of Parker 230R1230 - Fuel Filter Water Separator – Racor Spin-on Series

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker 230R1230 - Fuel Filter Water Separator – Racor Spin-on Series

Racor Spin-on Series Fuel Filter Water Separators provide maximum protection of modern engines by effectively removing water, sand, dirt, and rust contamination from fuel. Integral priming pump and fuel heater available as an option.
Availability:
Quote Required
Partner Available:Quote Required
Brand Parker
Part No. 230R1230
TBD
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
DivisionEngine Mobile Original Equipment DivisionBrandRacor
Operating Temperature-40 to 121 °CProduct TypeDiesel Spin-on FF/WS
Head MaterialAluminium AlloyFilter Element Type30 Micron Aquabloc Spin-on
Accessories IncludedSee Product Support TabMaximum Operating Pressure30 psi
Depth102.0 mmWidth4 inch
For Fluid TypeDieselNumber of Ports1 Inlet / 2 Outlet
Maximum Fluid Temperature88.0 °CHeight9 inch
Weight2 lb / 0.90 KgCompatible ElementR20S = "2" Micron<br/>R20T = 10 Micron<br/>R20P = 30 Micron
Clean Pressure Drop2.14 kPaLocationNorth America and EMEA regions
Micron Rating98% @ 30 MicronMountingBracket Included
Bowl TypeStandard, Clear Engineering PlasticPart TypeFilter Assembly
Port Size1/4" NPTFBowl MaterialClear Engineering Plastic
Product SeriesDiesel Spin-on 200Heater Power Rating12V / 300W (Diesel Only)
Integral Primer Pump IncludedHand Plunger Priming Pump (Diesel or Gasoline)Flow Rate30 gph (114 lph)
