Parker 15CN102QEEM2GS124 - Medium Pressure Inline Filters CN Series

The CN Series is a compact, cost effective, medium pressure filter designed with coreless filtration technology. CN Series bowl features a permanently fixed core designed to reduce solid waste and minimize disposal costs with every element change out.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 15CN102QEEM2GS124

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Housing Material	Aluminum	Product Type	Hydraulic Filter
Division	Engine Mobile Hydraulic and Fuel Filtration Division	For Fluid Type	Mineral, Petroleum and Polyalphaolefin (PAO) based fluids
Maximum Operating Temperature	107.0 °C	Product Style	Hydraulic Filter
Mounting Style	Inline	Weight	2.5 lbs (1.13 kg)
Port Type	SAE-12 straight threads	Pressure Rating	69 bar
Compatible Element	936698Q	Specifications Met	N/A
Filter Element Type	02Q Microglass	Seal Material	Ethylene Propylene
Flow Rate	20 gpm (75.7 lpm)	Options	Drain port
Indicator Type	Visual automatic reset	Port Connection Type	SAE-12 straight threads
Indicator Pressure Setting	25 psi (1.7 bar)	Bypass Valve Pressure Rating	25 psi (1.7 bar)
