Parker 150F-4-2 - Brass 45° Flare Fittings

Name: Parker 150F-4-2 - Brass 45° Flare Fittings
SKU: 150F-4-2
Price: 4.36 USD
Availability: InStock

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

Availability:

8 In Stock

Johnson City, TN	4
Richmond, VA	4

Partner Available:

193 In Stock

Brand Parker

Part No. 150F-4-2

$4.36

Qty:

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Brand	Parker
Division	Fluid System Connectors Division	Body Material	Brass
Technology	Fluid & Gas Handling	Division	Fluid System Connectors Division
Maximum Operating Temperature	250 °F	O-Ring Material	Fluorocarbon
Minimum Operating Temperature	-53 °C	Application	Adapters, Fuels, Natural Gas, Propane, Refrigerant Lines
Specifications Met	SAE J512, SAE J513	Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Nut Material	Brass	Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared
Maximum Operating Pressure	1,400 psi	Dimensional Weight	0.5518884892086331 lb
Connection 2 Type	Female Pipe	Connection 1 Type	Flare
Connection 1 Thread Size	7/16-20 inch	Connection 1 Tube Outside Diameter	1/4 inch
Connection 3 Tube Outside Diameter	NA	Shape	90° Forged Elbow
Connection 3 Type	NA	Connection 2 Thread Size	1/8 inch
Connection 3 Thread Size	NA	Connection 2 Tube Outside Diameter	NA
Product Style	Flare to Female Pipe
